Automatic Edge Bander with CE Certificate

Automatic EdgeBander with CE Certifiicate Characterisctics Edge-trimming unit with 2 HF Motor Micrometric adjustment with digital numerical read-out by control panel Edge-scrapping unit with digital numerical read-out by control panel Buffing unit with 2 motors with cloth dics diameters 150mm Height automatic adjustment of the units with digital numerical read-out by control panel Thermofusible glue tank with quick heating system Meets CE safety requriments Highlight: Nover construction,stable performance,easy operation,frequency converter for differentkinds of banding material. The Main Technical Parameters: Min Panel Length 168mm Band width 12-65mm Feeding speed 6-22M/min Feeding power 1.5Kw Machine size 3700×950×1750mm Workpiece thickness 10-60mm Panel width(min) 68mm Band thickness 0.4-15mm Pneumatic pressure 0.7Mpa Working Tempreture Range 180-200°C Trimming Cutter speed 12000rpm Total power 4.25kw Machine weight 1400kg
